Racing Polymer For Ford 370, 429, 460 16V OHV - MB5650TFC

Out of stock
The King Bearings TFC Series is tailored for Top Fuel, Funny Car, Pro Mod. The composite consists of high strength steel back, a special ductile Bronze lining, that resists extrusion & cracking, a XP Babbitt overlay with greater fatigue resistance and a polymer based coating layer.
Commonly use for Top Fuel, Funny Car, Pro Mod, and applications where bearings must withstand challenges such as metal-to-metal contact and deformation
Crankshaft Dim. Housing Dim. Length Thickness
76.21 / 76.18 mm
3.0002 / 2.9994 inch
81.10 / 81.08 mm
3.1930 / 3.1922 inch
Positions 1,2,4,5:
21.1 mm
0.831 inch

Position 3:
28.5 mm
1.124 inch
2.431 mm
0.0957 inch
Main Bearing Set For FORD 370, 429, 460 16V OHV - MB5650TFC

Performance features

Material features

Tech Features

Copper Based
Copper Based
Tri-Metal Copper based material

Leaded or Lead Free tri layers bearings for low to heavy load engines.

NitroKote™
nitrokote
Top Fuel polymer composite matrix

Polymer coated bearings, designed to withstand the metal-to-metal contact and extreme loading from 10,000 HP Top Fuel engines.

U-Groove™
u-groove
Greater load surface

A 90⁰ oil groove shape, keep oil flow intact, increases bearing load capacity by expanding the surface area.

Radialock™
Radialock
Optimal crush height and heat transfer

An optimal crush height value obtained from an optimization process of each performance bearing crush height

Eccentrix™
Eccentrix
Superior hydrodynamic lubrication

An optimized eccentricity value reached through elasto-hydrodynamic analysis and dynamic calculations.

Bulls Eye™
Bull's Eye Tolerance
PERFECT CLEARANCE IN EVERY SET

Outperforms the industry’s wall thickness tolerance, ensuring the least thickness variation shell-to-shell.

Lead free
Lead Free
Environmentally safe composite

A lead-free bearing material prioritizes environmental sustainability and safety, utilizing alternative compounds to achieve optimal performance in diverse applications.
